DECOLED light systems: how to connect, plug in and fasten them
Easy Fix, Eco Fix and Hobby Line. We explain how they differ, how to plug them into a socket, how many lights one run can carry and how to fasten the decoration safely.
Easy Fix in our online shopAccessoriesThree systems, three uses
Lights of one system and the same IP rating connect directly to each other, and the Max extension sets how many one run can carry. Do not combine the systems with each other, each works with a different voltage.
A professional 230 V system with a power supply cable with an AC/DC bridge. Rubber cable, IP44 or IP67 rating and a wide choice of lights and accessories. For houses, trees, facades and city decorations.
Low voltage 24 or 36 V from a transformer or power supply, depending on the type. Transparent or coloured cables, and on some strings crystals that sparkle even in daylight. Outdoors and indoors depending on the rating, often for 2D and 3D decorations.
A range for the home with a thin transparent or green cable and low voltage from a transformer. For smaller trees, windows and balconies.

How the lights connect
String lights and icicle lights have a male connector at one end and a female connector at the other. One of them has a union nut that you tighten to secure the joint. Decorations are either pass-through or end-type and are connected via a splitter. Lights of the same system and rating can be connected to each other.
- screw connector with a seal
- a rubber heat-shrink sleeve for the joint in the package
- an end cap goes on the end of the run
Easy Fix: connecting one run
Power supply cable
Start with the power supply cable. It includes an AC/DC bridge, which converts the alternating current from the mains into the direct current that LEDs need. Plug it into the socket only at the very end.
Lights in a row
With the plug pulled out, screw the lights onto the power supply cable one after another, working from the power source outwards. Pull out the plug every time you add or change a light as well.
Max extension
String 20 m: up to 10 pieces in a row (200 m). Icicle lights 3 m: up to 40 pieces (120 m). You will find the figure for each product. It applies to a run of identical lights. For a run made up of different lights and decorations, leave a reserve.
Secure the joints and plug in
Cover the joints with the sleeve from the package and shrink it with a heat gun or a hair dryer, and close the end of the run with an end cap. Only then put the plug into a weatherproof outdoor socket.

Diagram of one run from our guide: a power supply cable with an AC/DC bridge, 10 strings of 20 m each and a light-up star at the end.
Larger installations: several branches
When you need more lights than one run can carry, divide the installation into branches.
Use a power supply cable with a detachable AC/DC bridge. Behind the socket, split the installation with an Easy Fix splitter and connect a separate AC/DC bridge to each branch.
Another branch is fed by another power supply cable with a detachable bridge or by a standalone Easy Fix AC/DC bridge (480 W). Each branch with its own bridge has its own Max extension limit.
Easy Fix splitters have 2, 3, 7, 11 or 21 outputs. A splitter after the bridge does not create a new branch: everything behind one AC/DC bridge counts towards a single limit. You get a new branch only with another bridge.
They bridge the distance to the socket or between two places where the lights are. Lengths from 0.5 to 20 m, black and white.

Diagram of two branches from our guide: a splitter behind the socket and two branches, each with its own AC/DC bridge (2 power supply cables with a detachable bridge), with 7 strings of 20 m and 5 snowflakes connected via splitters. The upper branch ends with a star.
IP44 or IP67? Reductions between generations
Since 2019 we have made Easy Fix with IP67 connectors. They are shaped differently from the older IP44 ones, so they do not fit into each other directly. Outdoors you can use both ranges.
You will find the rating in the parameters and in the product name. Product codes with IP67 also contain the letter X, for example SLNX120W.
Do you have older IP44 lights at home and are adding new IP67 ones? Connect an IP44 to IP67 reduction behind the old light.
A new IP67 power supply cable with older IP44 lights behind it? Use an IP67 to IP44 reduction. Connect the reductions in order, starting from the power source.
Eco Fix and Hobby Line: transformer
The voltage of the light must match the voltage of the power source. You will find it in the name and parameters. 36 V lights go with a 36 V transformer (50, 100, 200 or 250 W), which you plug into the socket with a power supply cable without an AC/DC bridge. 24 V lights go with a standalone Eco Fix AC/DC 24 V power supply. Some Eco Fix extension cables have an IP20 rating and are for indoor use only.
Add up the power consumption of the connected lights and choose a transformer whose output covers the total. For example, an Eco Fix 8 m string with crystals has a power consumption of 5.76 W: on a 50 W transformer you can connect 8 of them, and for 12 pieces (the most in a row) you need 100 W.
The transformer is also the power source, so you do not need a power supply cable. It has an output of 12 W (with 8 animation programmes) or 15 W (with a controller and timer), and the total power consumption of the lights must not exceed it: a 20 m set has 7.5 W. Outdoor transformers have an IP44 rating.
Do not connect Eco Fix or Hobby Line lights to an Easy Fix power source or the other way round. Each system needs its own power source or transformer.
Fastening to the house and trees
You will find the detailed procedure with photos in the guide Installing Christmas lighting on a house, step by step.
The most common way: ties attach the cable to a hook, railing or fence.
Stretch it under the gutter and fasten the lights to it with ties. A loose wire would sag.
For heavier curtain lights and motifs. Fasten the decoration to it about every 10 cm.
For a facade, sheet metal or window sill, without drilling. They guide the supporting tie wire in a straight line.
Easy Fix accessories
Cables, splitters and other parts. For each part, check the rating and the plug type.
Frequently asked questions
Why is the power supply cable not in the package?
With interconnecting systems, one power source is enough for the whole run. You buy the power supply cable once and use it for further lights until you exceed the Max extension of the run. Light sets for the house and for trees include it in the package.
Can a single LED be replaced?
No. Each diode is encased in a polycarbonate cap that protects it from damage, snow, frost and sun.
How much energy do they use?
You will find the power consumption for each product. For example, an Easy Fix 20 m string with 120 LEDs has 9.2 W.
What is the difference between IP44 and IP67?
The higher the number after IP, the greater the protection against water and dust: IP44 protects against splashing water, IP67 also against brief immersion. Both ratings are designed for outdoor use, and Easy Fix with IP67 can stay outdoors all year round.
Can I connect lights of different systems?
No. Easy Fix, Eco Fix and Hobby Line work with different voltages, so connect each system only to its own power source.
